Power Seat Wiring Harness with J1939 Male To J1962 Female 6pin Deutsch Connector IP68 Waterproof for Heavy-Duty Vehicles
उत्पाद विवरण:
| उत्पत्ति के प्लेस: | ग्वांगडोंग, चीन |
| ब्रांड नाम: | Edgarcn & EdgarWireHarness |
| प्रमाणन: | IATF16949 TS16949 UL |
| मॉडल संख्या: | पावर सीट वायरिंग हार्नेस |
भुगतान & नौवहन नियमों:
| न्यूनतम आदेश मात्रा: | 10000 |
|---|---|
| मूल्य: | $8.88-10 |
|
विस्तार जानकारी |
|||
| कनेक्टर प्रकार: | Deutsch J1939 HD-16-9-1939S-P080 HD-10-9-1939P-P080 | केबल लंबाई: | अनुकूलित |
|---|---|---|---|
| रंग विकल्प: | लाल, काला, नीला, हरा | परिचालन तापमान: | -40 ℃ से +125 ℃ |
| कंपन प्रतिरोध: | 2 घंटे के लिए 10-2000Hz पर 20 g का | वाटरप्रूफ रेटिंग: | IP68 |
| विसर्जन की गहराई: | 24 घंटे के लिए 1.2 मीटर | टर्मिनल प्रकार: | 1060-16-0122 |
| तार का प्रकार: | उल 1007 18#, उल 1007 16# | संपर्क प्रतिधारण: | 20 पाउंड |
| तन्य: | > 20 एलबीएस (18#),> 25 एलबीएस (16#) | असफलता मॉडल: | तार क्षति, ग्रोमेट टूट गया |
| कनेक्टर सामग्री: | थर्माप्लास्टिक, सिलिकॉन रबर सील | पिन काउंट: | 9 पिन (J1939), 6 पिन (J1962) |
| संबंधक श्रृंखला: | ईडीजी-एचडी श्रृंखला | ||
| प्रमुखता देना: | J1939 Male To J1962 Female 6pin Deutsch Power Seat Wiring Harness,IP68 Waterproof Automotive Wiring Harness,Operating Temperature -40℃ to +125℃ Vehicle Cable |
||
उत्पाद विवरण
Power Seat Wiring Harness Truck Vehicle Cable
J1939 Male To J1962 Female 6pin Deutsch Harness for Truck
Model Numbers: D-16-9-1939S-P080, HD-10-9-1939P-P080
Product Description
The EDG-HD series is an environmentally silicone rubber sealed, thermoplastic cylindrical connector, designed for faster, easier, trouble-free assembly in heavy-duty industries including trucks, buses, cross-country vehicles, cranes, and forklifts. When mated, the contacts are protected from water, dust, lubricating oils, fuel, road salt, grease, mud, and other contaminants.
Product Specifications
- Operating temperature range: -40℃ to +125℃ with no cracking, chipping, or leaking after 20 test cycles
- Withstands sinusoidal vibration levels of 20 G's at 10 to 2000Hz in three mutually perpendicular planes for 2 hours without damage
- IP68 rating - waterproof and withstands immersion under 1.2 meters of water for 24 hours
Force Testing Results
EDG-HD10-9-1939P-P080
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
EDG-HD16-9-1939S-P080
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
Packaging and Shipping
Packaging details can be customized according to client specifications.
Standard Lead Times
| Quantity (PCS) | 1 - 1000 | 1001 - 5000 | >5000 | Mold/Tooling |
|---|---|---|---|---|
| Est. Time (Days) | 20 | 25 | To be negotiated | 30 days more |
International shipping available via DHL, UPS, FedEx, TNT, ARAMEX, and EMS. Customers may choose air, sea, or other shipping methods. Payment for samples/mass products required before delivery (amounts above $5000 USD negotiable).
Frequently Asked Questions
Q: Can you help with design?
A: Yes, we are an ODM/OEM company specializing in wire harness and cable assembly since 1999.
Q: When will you start to help design?
A: We provide initial sketches for discussion. After order confirmation, we create detailed drawings for client approval.
Q: What if quality issues occur?
A: Our quality team responds within 72 hours to resolve any issues, as we prioritize long-term customer relationships.
Q: Do you have standard products to reduce lead time and tooling costs?
A: Yes, we maintain over 1000 molds and 5000+ products developed through 20+ years of wire harness specialization.
